PPrinting Speed (n/a – accessory unit)
Wash Station Max Object Size (with platform): 180 × 121 × 153 mm
Wash Station Max Object Size (without platform): 201 × 124 × 255 mm
Wash Tank Volume: ≈ 7000 mL
Cure Station Max Object Size: Ø 200 × 260 mm
Control: Single rotary knob with integrated display, time setting 0-30 min
Light Source (Cure): 2 adjustable L-shaped bars (14 UV LEDs each) + 4 UV LED beads under turntable, wavelength 405 nm
Exposure: 360° auto-rotating turntable for uniform curing
Safety Cover: Transparent lid blocking ~99.9% UV rays, automatic UV shut-off when cover removed
Handheld UV Lamp: Included for targeted curing of nooks and internal parts
Wash Station Motor: Sealed tank with vortex cleaning mechanism & sealing rubber strip
Input Voltage: 110-240 V ~50/60 Hz
Rated Power – Wash Station: 12 W
Machine Dimensions – Wash: 255 × 155 × 385.5 mm; Net Weight: 2.27 kg
Machine Dimensions – Cure: 246 × 230 × 363.5 mm; Net Weight: 2.4 kg
Compatibility: Suitable for resin printed parts from wide range of LCD/DLP/SLA printers, including large formats
