Scan Mode: Structed Light Scan
Point Distance: 0.1 mm ~ 3 mm
Light Source: Infrared VCSEL structured light
Working Distance: Effective Working Distance: 160mm-1400mm Optimal Working Distance: 400mm
Depth of Field: 160-1400mm
Maximum FOV: 434mm*379mm (under optimal work distance)
Scan Speed: 980,000points/s, up to 14FPS
Align Modes: Feature Alignment, Hybrid Alignment, Texture Alignment, Global Markers
Safety: Eye-safe
Texture Scan: Yes
Interface: USB2.0 or above
Outdoor Scanning: Yes
Output Formats: OBJ; STL; PLY; P3; 3MF
Scanner Size: 220mm*46mm*55mm
Body Weight: 500g
Carrying Case Size: 245mm*245mm*90mm
Operating Temperature Range: 0-40℃
Operating Humidity Range: 10-90%
Recommended Configuration: OS: Win10/11, 64 bit;
Graphics card: NVIDIA GTX1050;
Video memory: ≥6GB;
Processor: I7-11800H;
Memory: ≥32GB
OS: MAC；
Apple Silicon: M1 Pro or higher (8-core GPU or more)；
RAM: 32GB or more；
USB: 2.0；
OS: macOS Ventura 13 or newer
Basic Computer Configuration
OS: Win10, 64 bit;
Graphics card: NVIDIA GTX1050;
Video memory: ≥4GB;
Processor: I7-7700H;
Memory: ≥16GB
OS: MAC；
Apple Silicon: M1 or higher (8-core GPU or more)；
RAM: 16GB or more；
USB: 2.0；
OS: macOS Ventura 13 or newer
Certifications: CE, FCC, ROHS, WEEE, KC
